Seiko Calibre V117A Solar Quartz Watch Movement

The Seiko V117A is a compact three-hand solar quartz movement that displays the hours, minutes, and central seconds. Its solar power-generation system converts light into electrical energy and stores it in an MT516F rechargeable battery.

When fully charged, the movement provides approximately six months of operating time. It also features overcharge prevention, second-hand stopping for accurate time setting, and an electronic circuit-reset function.

Movement compatibility depends on the watch case, dial configuration, hand fittings, stem position, solar-cell arrangement, and movement holder. Please compare all specifications with the existing movement before ordering. Professional installation is recommended.

Product Specifications
Calibre: Seiko V117A
Movement Type: Analogue Solar Quartz
Time Display: Hour, Minute and Central Seconds
Hand Movement: One-Second Intervals
Outside Dimensions: 12.05 × 15.55mm
Casing Dimensions: 11.80 × 15.15mm
Height: 2.39mm
Accuracy: Within ±15 Seconds per Month
Jewels: 2
Power Source: MT516F Rechargeable Battery
Power Reserve: Approximately 6 Months When Fully Charged
Additional Functions: Overcharge Prevention, Second-Hand Stop and Electronic Circuit Reset
Installation: Professional Installation Recommended
